■ High
efficient, convenient, compact and economic ozone
generators
■ Can be use feed gas as oxygen or dry air
■ Operation with negative or positive pressure
Can be used in laboratory field, environment
field, chemical field,
agriculture field, and used for purification of
wastewater and irrigation water,
reaction test of ozone with other materials. This
generates ozone of 10.0 GM/HR
when used oxygen and 4.0 GM/HR when used dry air.
Also, this ozone generator is
easily installed.
특징 (Features)
* Triogen LAB 2B 는 세계 굴지의 Ozonia사가 첨단 기술을 적용하여 Lab용으로 제작한
고성능, 최소화, 초간편, 최저렴한 Ozone 발생기임.
* Oxygen 이나 Dry Air 를 Feed Gas 로 사용할 수 있으며, Negative 나 Positive Pressure로
작동되는 유일 기종임.
* 최대 용량은 Oxygen 사용시 10.0GM / HR, Dry Air (-60℃ Dewpoint )사용시 4.0 GM / HR
* 설치가 간편함.
용도 (Applications)
* 환경분야, 수질개선, 폐수 정화, 농업분야, 양어장, 농장의 관개수, 화학분야, 타물질과
Ozone 반응시험에 적합한 기종임.
규격 (Specificaions)
* Ozone Output(Max : 4.0 GM/HR (Feed gas : Dry air -60℃ Dewpoint)
* Ozone Output(Max : 10.0 GM/HR (Feed gas : Oxygen Bottle)
* Feed Gas Flow rate : 4 - 10 Lit. Dry air, 2 - 5 Lit.. Oxygen
* Operating Method : Vacum or Pressure (1.0 bar.g. max.)
* Module Cooling Medium : Ambient Air(Fan assisted)
* Variable output control : 15 - 100 %
* Connections : PVDF compression fitting to suit od 8 mm pipe
|
