■ Intrinsically safe Certified.
■ Hand held and Cordless
■ Include all pneumatic and Electronic components.
■ Simple to use, quickly familiar with the essential feature
of Hydrosteel operatin and deployment.
Hydrosteel technology enables fast direct measurement and monitoring
of mobile(diffusible) hydrogen in steel, from the surface of the smallist
pipe to the largest vessel.
Hydrosteel 6000 is cerified intrinsically safe, completely solide state,
requires minimal servicing and doesnot require consumables.
Test site preperation is often unnecessary.
특징 (Features)
* Hydrosteel 기술로 빠르고 직접적인 측정과 작은 파이프의 표면에서부터
큰 베셀(Vessel)까지 강철내의 수소의 움직임(Diffusible)을 볼수 있음.
* Test Surface의 온도는 650℃ (1200℉)까지 가능.
* Probes : LT-R, HT-R, HT-S
* Probe 나 ‘Hydrogen Collector’를 철에 부착함으로써 Gas Sample Tubing을
통해서 관내 주변의 공기가 일정한 Test Surface로 모이게 되고 내부 공기중 수소의
농도가 짙어지는 곳에서 Hydrosteel Analyser가 작동되면서 일정량의 수소기체가
흐르게 됨.
* Standard Gas Sample Tubing : Hydrosteel Equipment와 함께 공급
(2’6” and 6’6” In Length)
* Hydrosteel 6000 Power Packs : Up to 1 month’s monitoring, to intrinsically
safe design, specialist probes 공급가능(문의요함).
규격 (Specifications)
* Test Surface의 Low & High 온도에서 유량측정을 최적화하고 공기의 순환
(Roaming)과 정체(Stationary)를 위한 Probes를 다음의 표에 의해 선택할수 있음.
* Measurement Method : Hydrogen Collection and Analysis
* Hydrogen Flux Resolution : LT : ±1pl/cm2·S HT : ±5pl/cm2·S
(1pl being 10-9ml at 1bar, 25℃)
* Dynamic Range : LT : 0 to 3500pl/cm2·S, HT : 0 to 15000pl/cm2·S
* Accuracy : ±10% Reading, or Resolution, Whichever is greater
* Weight : Analyser+Collector=2.5lb (1.2kg)
* Steel Surface Temperature : LT-R : -40+130℃, -40+265℉
HT-R : -40+500℃, -40+930℉
HT-S : -40+650℃, -40+1200℉
* Ambient Temperature (Analyser) : -15 to 40℉, -20 to 50℃
* Steel Curvature Tolerance : LT-R : >3.5" diameter, HT-R : >8" diameter
HT-S : >2" diameter
* Internal Power Requirements : 4×1.5V Alkaline Type AA Batteries
* External Power Requirements : 6V d.c. 150mA Minimum
* Safety : BASEEFA EE×ia IIC T4, -20 to 60℃
|
