주요특징 (Main Features)

* 다용도/기능추가형 : Homogenizer, PC Software 등 다양한 기능을 추가 및 교체할 수 있음.
* 용도별/기능별 Double-Walled Reactor  Vessels와 Covers의 선택이 자유롭다.
  (1) 2Lit.Vessels : Glass or Stainless steel재질, With or Without Bottom Outlet Value
  (2) Vessel Covers : 5× Joint Necks(5구), With FFPM Seal(230℃내열) or Viton™
      Seals(180℃내열), 3×29 necks and 2× 14/23 Glass Joints.
* 최소화 작업 공간에서의 극대화 작업 효율성이 보장되는 System-Technique의 개가.
* Lever Handle식 “Up & Down” Light System : Vessel 및 Base(바닥 stand)를 제외한 모든
  장치가 레바 핸들의 작동으로 올려지고 내려지므로 위치잡기에 편리함.<높이조절식>
* Robust, Stable, and Anti-Tilt Construction, 튼튼하고 안전하며, 완벽한 균형


용도 (Applications)

Designed and Configured for Simulating and Optimizing Chemical Reaction Processes
as well as Mixing, Dispersing, and Homogenizing Processes on a Smaller Scale.
Some Examples of Development Tasks are :
·Manufacturing Creams, Lotion, Emulsions, Liposome Preparations in the Pharmaceutical
  and Cosmetic Sector
·Mixing Solids such as Calcium Carbonate, Talc, Titanium Oxide, etc. into Liquid Polymers
·Mixing Additives and Solid Polymer Compounds into Mineral Oils
·Grinding and Disintegrating Solids and Fibers in Liquids and Polymers

주요규격 (Main Specifications for LR2000.70™ Base Unit)

* Working Capacity : 500 ~ 2000 ml
* Dispersing Capacity : 800 ~ 2000 ml, IKA T25™ Homogenizer 사용의 경우
* Speed : 8 ~ 290  rpm
* Vacuum : 25 mbar
* Lift, 높낮이 조절 : 26 cm
* Viscosity range : up to 150,000mPas
* 실험물질과의 접촉 부분의 재질 :
  (1) Teflon PTFE, FFPM or Viton™
  (2) Stainless Steel or DURAN™ Glass α3.3<특급유리>
* Temp.(max) :
  (1) FFPM Seal인 경우 230℃
  (2)Viton™ Seal인 경우180℃
* Size : w40×d50×h100 cm,  Weight of Basic device : 30 kg
